| 轴承型号 | 内径 | 外径 | 宽度 | 倒角 | 额定载荷(KN) | 钢球参数 | 极限转速(转/分) | 重量 | ||||||
| d | D | B | r/min | Dynamic | Static | No. | Size | Grease | Oil | kg | ||||
| mm | in | mm | in | mm | in | mm | Cr | Cor | mm | r/min | r/min | |||
| 692 | 2 | 0.07874 | 6 | 0.23622 | 3 | 0.11811 | 0.15 | 0.1 | 6 | 7 | 1.588 | 86000 | 100000 | 0.0004 |
| 693 | 3 | 0.11811 | 8 | 0.31496 | 4 | 0.15748 | 0.15 | 0.17 | 6 | 7 | 2.381 | 64000 | 76000 | 0.0008 |
| 694 | 4 | 0.15748 | 11 | 0.43307 | 4 | 0.15748 | 0.15 | 0.715 | 0.276 | 7 | 2.381 | 45000 | 52000 | 0.0018 |
| 695 | 5 | 0.19685 | 13 | 0.51181 | 4 | 0.15748 | 0.2 | 1.08 | 0.43 | 8 | 3.5 | 34000 | 43000 | 0.0024 |
| 696 | 6 | 0.23622 | 15 | 0.59055 | 5 | 0.19685 | 0.2 | 1.35 | 0.53 | 8 | 3.969 | 32000 | 40000 | 0.0038 |
| 697 | 7 | 0.27559 | 17 | 0.66929 | 5 | 0.19685 | 0.2 | 1.61 | 0.715 | 9 | 3.969 | 30000 | 38000 | 0.0052 |
| 698 | 8 | 0.31496 | 19 | 0.74803 | 6 | 0.23622 | 0.3 | 1.99 | 0.865 | 7 | 4.763 | 28000 | 36000 | 0.0073 |
| 699 | 9 | 0.35433 | 20 | 0.7874 | 6 | 0.23622 | 0.3 | 2.48 | 1.09 | 9 | 4.763 | 27000 | 34000 | 0.0082 |
| 6900 | 10 | 0.3937 | 22 | 0.86614 | 6 | 0.23622 | 0.5 | 2.7 | 1.27 | 12 | 5.953 | 25000 | 32000 | 0.009 |
| 6901 | 12 | 0.47244 | 24 | 0.94488 | 6 | 0.23622 | 0.5 | 2.89 | 1.46 | 9 | 6.35 | 20000 | 28000 | 0.011 |
| 6902 | 15 | 0.59055 | 28 | 1.10236 | 7 | 0.27559 | 0.5 | 4.1 | 2.06 | 10 | 6.747 | 19000 | 26000 | 0.016 |
| 6903 | 17 | 0.66929 | 30 | 1.1811 | 7 | 0.27559 | 0.5 | 4.65 | 2.58 | 11 | 6.747 | 18000 | 24000 | 0.018 |
| 6904 | 20 | 0.7874 | 37 | 1.45669 | 9 | 0.35433 | 0.5 | 6.4 | 3.7 | 11 | 7.938 | 17000 | 22000 | 0.036 |
| 6905 | 25 | 0.98425 | 42 | 1.65354 | 9 | 0.35433 | 0.5 | 7.05 | 4.56 | 13 | 7.938 | 14000 | 18000 | 0.042 |
| 6906 | 30 | 1.1811 | 47 | 1.85039 | 9 | 0.35433 | 0.6 | 7.25 | 5 | 14 | 9.525 | 12000 | 16000 | 0.148 |
| 6907 | 35 | 1.37795 | 55 | 2.16535 | 10 | 0.3937 | 0.6 | 11.2 | 7.45 | 14 | 11.112 | 10000 | 14000 | 0.074 |
| 6908 | 40 | 1.5748 | 62 | 2.44094 | 12 | 0.47244 | 0.6 | 14.5 | 10.2 | 14 | 12 | 8000 | 12000 | 0.11 |
| 6909 | 45 | 1.77165 | 68 | 2.67716 | 12 | 0.47244 | 0.6 | 15.1 | 11.2 | 15 | 12 | 6000 | 10000 | 0.128 |
| 6910 | 50 | 1.9685 | 72 | 2.83464 | 12 | 0.47244 | 0.6 | 15.6 | 12.2 | 16 | 12.7 | 4000 | 8000 | 0.132 |
| 6911 | 55 | 2.16535 | 80 | 3.1496 | 13 | 0.51181 | 1.5 | - | - | - | - | - | - | 0.397 |
| 6912 | 60 | 2.3622 | 85 | 3.34645 | 13 | 0.51181 | 1.5 | - | - | - | - | - | - | 0.425 |
| 6913 | 65 | 2.55905 | 90 | 3.5433 | 13 | 0.51181 | 1.5 | - | - | - | - | - | - | 0.454 |
| 6914 | 70 | 2.7559 | - | - | - | - | - | - | - | - | - | - | - | - |
| 6915 | 75 | 2.95275 | - | - | - | - | - | - | - | - | - | - | - | - |
| 6916 | 80 | 3.1496 | - | - | - | - | - | - | - | - | - | - | - | - |
| 6917 | 85 | 3.34645 | - | - | - | - | - | - | - | - | - | - | - | - |
| 6918 | 90 | 3.5433 | - | - | - | - | - | - | - | - | - | - | - | - |
| 6919 | 95 | 3.74015 | - | - | - | - | - | - | - | - | - | - | - | - |
| 6920 | 100 | 3.937 | 140 | 5.5118 | 20 | 0.7874 | 2 | 0.079 | - | - | - | - | - | 1.73 |
应用领域：深沟球轴承可用于变速箱、仪器仪表、电机、家用电器、内燃机、交通车辆、农业机械、建筑机械、工程机械、滚轴式轮滑鞋、悠悠球等。
东莞市肯铁轴承有限公司，20多年不锈钢轴承生产厂家，现货批发，OEM,ODM，欢迎来电咨询。
肯铁轴承技术服务热线：13392733900 段生 （微信同号）
